panasonic plug-in machine RL131

 ‌The main advantages of Panasonic RL131 plug-in machine include the following aspects‌:

‌Efficient production‌: Panasonic RL131 plug-in machine adopts a fully automatic production mode, including upper and lower boards and fully automatic plug-in functions, which can achieve 100% plug-in rate without manual intervention, significantly improving production efficiency‌

‌High precision and flexibility‌: The plug-in head can be rotated, supporting plug-in in four directions of 0°, -90°, 90° and 180°, thanks to the independent drive of the AC servo motor, which allows the plug-in head and the axis unit to work independently. This design not only reduces the fixed time loss of table rotation, but also improves the flexibility of high-density board NC program, further improving production efficiency. ‌

‌High-density insertion‌: Through the guide pin method, the RL131 plug-in machine can achieve high-density insertion without dead corners, with few restrictions on the insertion order, and can switch different insertion pitches (2 pitches, 3 pitches, 4 pitches), which is suitable for the insertion needs of various components. ‌

‌Fast insertion‌: The plug-in machine supports high-speed insertion, and large components can also achieve high-speed insertion of 0.25 seconds to 0.6 seconds, which significantly improves production speed. ‌

‌Versatility‌: The RL131 plug-in machine provides a variety of specifications, including 2-pitch, 3-pitch and 4-pitch models, which can meet different production needs. In addition, it also supports the insertion of substrates with a maximum size of 650mm×381mm, further expanding its application range. ‌
